Q-ROI Navigation System on Android with Monitor for BMW 3 Series
sales team
Q-ROI navigation system with inputs for connecting rear view cameras and other aftermarket video sources to BMW 3S OEM monitors. Navigation system works on Android 4.2.2 platform allowing you to expand the device functionality by various programs and applications from Google Play.
This adapter is equipped with the active parking guidelines function (PAS).
Features
- Aftermarket navigation on your OEM monitor
- Connect rear view camera
- Play media content
- USB inputs
- Navigation output resolution
- 800×480
Q-ROI navigation system with inputs for connecting rear view cameras and other aftermarket video sources to BMW 3S OEM monitors. Navigation system works on Android 4.2.2 platform allowing you to expand the device functionality by various programs and applications from Google Play.
This adapter is equipped with the active parking guidelines function (PAS).
Features
- Aftermarket navigation on your OEM monitor
- Connect rear view camera
- Play media content
- USB inputs
- Navigation output resolution
- 800×480
Technical Specifications
| System: | CPU | Telechips TCC8930 (1GHz Cortex A9 DualCore) |
| OS | Android 4.2.2 Jelly Bean | |
| RAM | DDR3 1 GB | |
| ROM | 8 GB eMMC | |
| Language | Multilingual | |
| GPS | Supported systems | GPS |
| Chipset | SiRF | |
| Outputs | RGB |
800 × 480 |
| LVDS | 1 | |
| Inputs |
AV | 3 |
| Rear view camera connection | 1 | |
| Data | USB | USB 2.0 ×1 |
| Slot for memory card | SDHC (up to 64 GB) | |
| General | Power | 12 V |
| Supported type of touch screen | Resistive |
Compatibility
| Brand | Model | Model years | Monitor | |
|---|---|---|---|---|
| From | To | |||
| 3 Series | F30 | 2011 | 2015 | 6,5″ |
| F31 | ||||
Note! For installation of the navigation system it is necessary to replace your monitor with the one incuded in the package content.
Manuals
- Download user manual for Q-ROI navigation system
- Download installation manual for Q-ROI navigation system
Package Content
- 8.8" monitor
- Navigation system
- Connection cables
- Power cable
- AV cable
- 6-pin LVDS cable
- Rear view camera cable
- Mode switch cable
- USB cable
- Microphone cable
- Multi cables
- SD extension cable
- GPS antenna
- Wi-Fi dongle
- 3G dongle
- B/T board
Note! Installation of the navigation system should be performed by a well-trained specialist. Otherwise, we are not liable for equipment damage or incorrect operation.
