Rear Camera Cable 16 pin for Toyota Camry, Corolla, RAV4, Highlander, Tacoma, Prius / Scion tC, xB, FR-S / Subaru Forester, Crosstrek, Impreza, WRX, BRZ, XV
USD 15.00
Rear Camera Cable 16 pin for Toyota Camry, Corolla, RAV4, Highlander, Tacoma, Prius / Scion tC, xB, FR-S / Subaru Forester, Crosstrek, Impreza, WRX, BRZ, XV
id: 860038
Rear Camera Cable 16 pin for Toyota Camry, Corolla, RAV4, Highlander, Tacoma, Prius / Scion tC, xB, FR-S / Subaru Forester, Crosstrek, Impreza, WRX, BRZ, XV
Overview
Description
Specifications
Delivery
Payment
Warranty
USD 15.00
Overview
0.05 kg
Availability in stock:
HK EU
Warranty: 24 months The harness 16 pin for rear view camera connection to the OEM monitors of Toyota Camry, Corolla, RAV4, Highlander, Tacoma, Prius, etc. 2010-2015 MY with Touch system, Scion tC, xB, FR-S, etc. 2013-2015 MY with Bespoke system, Subaru Forester, Crosstrek, Impreza, WRX, BRZ, XV 2012-2015 MY with SD Navi system without damaging the car wires. Read more
COMBO OFFERS
Frequently bought together
Bestseller
ID: 883474
Universal 170° Reverse Parking Camera 720P
USD 30.00
USD 25.00
Universal rear view camera in waterproof case HD-960P. 170° view angle.
Availability in stock:
HK
ID: 883474 0.3 kg
Bestseller
ID: 896301
Universal 120° Reverse Parking Camera 720P
USD 30.00
USD 25.00
Universal rear view camera in waterproof case HD-960s. 120° view angle.
Availability in stock:
HK
ID: 896301 0.2 kg
Universal camera with excellent image quality. Waterproof (IP68 class). Color - black.
Availability in stock:
HK
ID: 891696 0.24 kg
ID: 891697
Universal 170° Car Camera 720P (cube)
USD 30.00
USD 25.00
Universal camera with excellent image quality. Waterproof (IP67 class). Color - black.
Availability in stock:
HK
ID: 891697 0.2 kg
Universal camera with excellent image quality. Waterproof (IP68 class). Color - black.
Availability in stock:
HK
ID: 875106 0.2 kg
Description
Cable for rear view camera connection to the OEM monitors of Toyota with Touch system, Scion with Bespoke system, Subaru with SD Navi system. Using this cable you will be able to install the aftermarket camera Plug&Play without damaging the car wires.
Image from the rear view camera will automatically be displayed on the screen when reversing. The device is connected to the 16 pin socket (as shown in the connection diagram). After connection all OEM functions which work using this socket are preserved due to transit type of connection.
Note! The additionally installed rear view camera should be powered from ACC line (first turn of the key), otherwise the camera input will be not active. Depending on the type of the camera to be connected, namely the operating voltage, you can use power converter to decrease heating of the linear power supply which is built in the camera. In case the camera requires more than +6 V, connect the camera power directly to ACC line.
The most frequently asked questions about camera and video connection cables.
Compatibility
Toyota
| Model | Model Years | System / Monitor | Additional compatibility conditions | |
|---|---|---|---|---|
| From | To | |||
| Auris | 2010 | 2014 | Touch Touch&Go Touch&Go Plus |
16 pin socket on the monitor for cables connection |
| Auris Hybrid | 2010 | 2014 | ||
| Avensis | 2011 | 2014 | ||
| Camry | 2011 | 2014 | ||
| Camry Hybrid | 2011 | 2014 | ||
| Corolla | 2011 | 2013 | ||
| Fortuner | 2011 | 2014 | ||
| GT86 | 2012 | 2015 | ||
| Highlander | 2012 | 2014 | ||
| Highlander Hybrid | 2012 | 2014 | ||
| Hilux | 2011 | 2014 | ||
| Matrix | 2011 | 2014 | ||
| Prius | 2011 | 2014 | ||
| Prius C | 2012 | 2014 | ||
| Prius MPV+ | 2012 | 2014 | ||
| Prius Plug-in Hybrid | 2012 | 2014 | ||
| RAV4 | 2010 | 2014 | ||
| Tacoma | 2012 | 2014 | ||
| Venza | 2013 | 2014 | ||
| Verso | 2009 | 2014 | ||
| Verso S | 2010 | 2014 | ||
| Yaris | 2011 | 2014 | ||
| Yaris Hybrid | 2012 | 2014 | ||
Scion
| Model | Model years | System/Monitor | Additional compatibility conditions | |
|---|---|---|---|---|
| From | To | |||
| FR-S | 2013 | 2015 | Bespoke | 16 pin socket on the monitor for cables connection |
| iQ | 2013 | 2015 | ||
| xB | 2013 | 2015 | ||
| xD | 2013 | 2015 | ||
| tC | 2013 | 2015 | ||
Subaru
| Model | Model years | System | Monitor | Additional compatibility conditions | |
|---|---|---|---|---|---|
| From | To | ||||
| BRZ | 2013 | 2014 | SD Navi | FA601US FA632US FA732CS FE678US FE688US FE699US FF215KS FF605US FF615US FM201KS FM401LS FM412LS FM601US FM612US FM622US FM702US FM722US FP606US FV219KS FW602US |
16 pin socket on the monitor for cables connection |
| FRS | 2013 | 2014 | |||
| Forester | 2012 | 2014 | |||
| Impreza | 2012 | 2014 | |||
| Impreza WRX | 2012 | 2014 | |||
| Trezia | 2012 | 2014 | |||
| XV | 2013 | 2014 | |||
| XV Crosstrek | 2013 | 2014 | |||
| WRX | 2014 | 2015 | |||
| WRX STI | 2014 | 2015 | |||
Note! Only cameras in NTSC format are supported.
The photo is provided for reference only. Appearance of the control panel and monitor may slightly differ depending on the car model.
Manuals
Package Content:
- Cable for Rear View Camera Connection - 1 pc.
Product specifications, appearance and package content may differ from those presented on the website and can be changed without notice. Please, contact sales manager before purchase.
All rights reserved. This material from car-solutions.com web site may not be published, rewritten or redistributed in whole or part without authorship indicated and backlinks provided.
Specifications
| Cable for OEM Head Unit is compatible with Head Units |
|
| Cable for OEM Head Unit is compatible with Camera Connection |
|
