Camera Transmitter and Receiver for Connection to GPS
sales team
The colour camera transmitter and receiver is perfect decision for car camera connection to GPS navigator or any other device with mini USB input.
Transmitter is connected to your camera and receiver - to the navigator and power cable (of the navigator or any other device the camera is connected to). Thus, the video signal from the car camera is transmitted via 2.4 GHz frequency radio channel to your device and the image is displayed on it screen.
Camera Transmitter and Receiver
Connection
Camera Transmitter and Receiver
Technical Specifications
| Transmission distance (without interference & obstacles) | 100 m | |
| Input resistance | 75 Ohm | |
| Demodulation | 2.4 GHz | |
| Intermediate frequency band | 18 MHz | |
| High receiver sensitivity | -90 dBm | |
| AV output | Composite | |
| Weight | receiver | 30 g |
| transmitter | 44 g | |
| Dimensions | receiver | 60 mm × 32 mm |
| transmitter | 60 mm × 32 mm | |
| Transmitter Cable lengthc | 1.3 m | |
| Working temperature | -20°C to +60°C | |
| Working current | 200 mA | |
Camera Transmitter and Receiver
Package Content
- Video signal receiver
- Video signal transmitter
The colour camera transmitter and receiver is perfect decision for car camera connection to GPS navigator or any other device with mini USB input.
Transmitter is connected to your camera and receiver - to the navigator and power cable (of the navigator or any other device the camera is connected to). Thus, the video signal from the car camera is transmitted via 2.4 GHz frequency radio channel to your device and the image is displayed on it screen.
Camera Transmitter and Receiver
Connection
Camera Transmitter and Receiver
Technical Specifications
| Transmission distance (without interference & obstacles) |
100 m | |
| Input resistance | 75 Ohm | |
| Demodulation | 2.4 GHz | |
| Intermediate frequency band | 18 MHz | |
| High receiver sensitivity | -90 dBm | |
| AV output | Composite | |
| Weight | receiver | 30 g |
| transmitter | 44 g | |
| Dimensions | receiver | 60 mm × 32 mm |
| transmitter | 60 mm × 32 mm | |
| Transmitter Cable lengthc | 1.3 m | |
| Working temperature | -20°C to +60°C | |
| Working current | 200 mA | |
Camera Transmitter and Receiver
Package Content
- Video signal receiver
- Video signal transmitter
| Accessory is compatible with |
|
