Car Digital DVB-T TV Receiver with PVR Function
sales team
Car DVB-T receiver with PVR function as connected to your car monitor allows you to watch and record digital TV programs directly in your car. * This digital DVB-T MPEG4 TV tuner provides consistent reception at the rate of 250 km/hour. Three RCA video output allow connecting additional monitors (for example, headrest monitors). The device can be used not only in the car but at home together with your TV set.
Car DVB-T Receiver
Features
- PVR function
- PIP (picture in picture) support
- Automatic and manual channels search
- Memory for over 1000 channels
- OSD teletext support
- Software upgrade via USB port
- Three RCA video outputs for additional monitors connection
- 13 languages (English, German, French, Russian, Spanish, Romanian, Greek, Swedish, Slovak, Arabic, Danish, Estonian, Hebrew) support
- IR eye for remote control unit
Car DVB-T Receiver
Technical Specifications
| Signal | Input signal frequency | UHF: 474 MHz to 858 MHz |
| VHF: 177.5 MHz to 226.5 MHz | ||
| Modulation | QPSK / 16-QAM/64-QAM | |
| Bandwidth | 6 / 7 / 8 MHz | |
| Decoding standards | Video | MPEG2, [email protected], [email protected], H.264/AVC |
| Audio | MPEG-1, MPEG-2, MPEG-4, HE_AAC | |
| Audio and Video | 3 video outputs | Output impedance: 75 Ohm |
| Output voltage: 1.0±2.0 mV | ||
| Audio output | 2 V | |
| HDMi output | 1280 px × 720 px | |
| 1920i × 1080i | ||
| Power | Supply | 12 V DC |
| Consumption | 8 W | |
| Dimensions | Without connectors | 178 mm × 116 mm × 26 mm |
| With connectors | 178 mm × 138 mm × 26 mm | |
| Temperature | Operation | -15°C to +40°C |
| Storage | -20°C to +60°C |
Car DVB-T Receiver
Manuals
Car DVB-T Receiver
Package Content
- DVB-T receiver module
- Antenna × 2
- Remote control unit
- Cable set
- Power cable
- A/V cable
- IR eye cable
- Cigarette lighter power cable
- Mounting package
Note! Before purchasing this car DVB-T receiver please check DVB-T coverage in your region.
Various Digital TV Formats Coverage Map
Car DVB-T receiver with PVR function as connected to your car monitor allows you to watch and record digital TV programs directly in your car. * This digital DVB-T MPEG4 TV tuner provides consistent reception at the rate of 250 km/hour. Three RCA video output allow connecting additional monitors (for example, headrest monitors). The device can be used not only in the car but at home together with your TV set.
Car DVB-T Receiver
Features
- PVR function
- PIP (picture in picture) support
- Automatic and manual channels search
- Memory for over 1000 channels
- OSD teletext support
- Software upgrade via USB port
- Three RCA video outputs for additional monitors connection
- 13 languages (English, German, French, Russian, Spanish, Romanian, Greek, Swedish, Slovak, Arabic, Danish, Estonian, Hebrew) support
- IR eye for remote control unit
Car DVB-T Receiver
Technical Specifications
| Signal | Input signal frequency | UHF: 474 MHz to 858 MHz |
| VHF: 177.5 MHz to 226.5 MHz | ||
| Modulation | QPSK / 16-QAM/64-QAM | |
| Bandwidth | 6 / 7 / 8 MHz | |
| Decoding standards | Video | MPEG2, [email protected], [email protected], H.264/AVC |
| Audio | MPEG-1, MPEG-2, MPEG-4, HE_AAC | |
| Audio and Video | 3 video outputs | Output impedance: 75 Ohm |
| Output voltage: 1.0±2.0 mV | ||
| Audio output | 2 V | |
| HDMi output | 1280 px × 720 px | |
| 1920i × 1080i | ||
| Power | Supply | 12 V DC |
| Consumption | 8 W | |
| Dimensions | Without connectors | 178 mm × 116 mm × 26 mm |
| With connectors | 178 mm × 138 mm × 26 mm | |
| Temperature | Operation | -15°C to +40°C |
| Storage | -20°C to +60°C |
Car DVB-T Receiver
Manuals
Car DVB-T Receiver
Package Content
- DVB-T receiver module
- Antenna × 2
- Remote control unit
- Cable set
- Power cable
- A/V cable
- IR eye cable
- Cigarette lighter power cable
- Mounting package
Note! Before purchasing this car DVB-T receiver please check DVB-T coverage in your region.
Various Digital TV Formats Coverage Map
