CS-A440K Navigation System on Android 4.4 for Kenwood Multimedia Receivers
sales team
CS-A440K navigation system for connection to Kenwood multimedia receiver with 800×480 resolution. Such receivers started to be manufactured approximately from 2012. The module offers full-service navigation with touch screen control and Plug&Play connection.
*Note! If you want to connect navigation on Android to OEM car monitor, you will need Andromeda navigation box.
CS-A440K Navigation System
Features
- Touch screen control
- Sound reproduced by the OEM speakers*
- Switching to navigation by the OEM button*
- Built-in Wi-Fi module
- USB inputs
- Slot for SD card
- Connection to Internet via 3G modem
- Connection to OEM antenna via special adapter
* You can adjust that according to the manual for your Kenwood receiver.
Note! 3G modem and antenna adapter are not included in the package.
CS-A440K Navigation System
Technical Specifications
| Operating system | Android 4.4 |
| Processor | Dual-Core 1.2 GHz |
| RAM | DDR3 1 GB |
| ROM | Flash eMMC 4 GB |
| RGB output resolution | 800X480 |
| Wi-Fi | 802.11b/g/n |
CS-A440K Navigation System
Compatibility
| Kenwood receiver model | Compatibility condition |
|---|---|
| KW-DDX3023 | 800×480 HD Version |
| KW-DDX4023 | |
| KW-DDX4025BT | |
| KW-DDX4028 | |
| KW-DDX4031BTM | |
| KW-DDX4033BTM | |
| KW-DDX4038 | |
| KW-DDX5032 | |
| KW-DDX5036 | |
| KW-DDX6023BT | |
| KW-DDX6033BTM | |
| KW-DDX6034 | |
| KW-DDX6039 | |
| KW-DDX630BT | |
| KW-DDX630WBTM | |
| KW-DDX7025BT | |
| KW-DDX7035 | |
| KW-DDX7036 | |
| KW-DDX7039 | |
| KW-DDX8036 | |
| KW-DDX8039 |
CS-A440K Navigation System
Manuals
CS-A440K Navigation System
Package Content
- CS-A440K navigation system
- Connection cables
- GPS antenna
Note! 3G modem and antenna adapter are not included in the package.
Note! Navigation system installation shall be performed by well-trained specialist. Otherwise, we are not liable for equipment damage or incorrect operation.
CS-A440K navigation system for connection to Kenwood multimedia receiver with 800×480 resolution. Such receivers started to be manufactured approximately from 2012. The module offers full-service navigation with touch screen control and Plug&Play connection.
*Note! If you want to connect navigation on Android to OEM car monitor, you will need Andromeda navigation box.
CS-A440K Navigation System
Features
- Touch screen control
- Sound reproduced by the OEM speakers*
- Switching to navigation by the OEM button*
- Built-in Wi-Fi module
- USB inputs
- Slot for SD card
- Connection to Internet via 3G modem
- Connection to OEM antenna via special adapter
* You can adjust that according to the manual for your Kenwood receiver.
Note! 3G modem and antenna adapter are not included in the package.
CS-A440K Navigation System
Technical Specifications
| Operating system | Android 4.4 |
| Processor | Dual-Core 1.2 GHz |
| RAM | DDR3 1 GB |
| ROM | Flash eMMC 4 GB |
| RGB output resolution | 800X480 |
| Wi-Fi | 802.11b/g/n |
CS-A440K Navigation System
Compatibility
| Kenwood receiver model | Compatibility condition |
|---|---|
| KW-DDX3023 | 800×480 HD Version |
| KW-DDX4023 | |
| KW-DDX4025BT | |
| KW-DDX4028 | |
| KW-DDX4031BTM | |
| KW-DDX4033BTM | |
| KW-DDX4038 | |
| KW-DDX5032 | |
| KW-DDX5036 | |
| KW-DDX6023BT | |
| KW-DDX6033BTM | |
| KW-DDX6034 | |
| KW-DDX6039 | |
| KW-DDX630BT | |
| KW-DDX630WBTM | |
| KW-DDX7025BT | |
| KW-DDX7035 | |
| KW-DDX7036 | |
| KW-DDX7039 | |
| KW-DDX8036 | |
| KW-DDX8039 |
CS-A440K Navigation System
Manuals
CS-A440K Navigation System
Package Content
- CS-A440K navigation system
- Connection cables
- GPS antenna
Note! 3G modem and antenna adapter are not included in the package.
Note! Navigation system installation shall be performed by well-trained specialist. Otherwise, we are not liable for equipment damage or incorrect operation.
