Navigation Box on Android for Lexus OEM Monitors with Joystick or Touchpad
Overview
You may also like
Description
This navigation box is used to connect GPS navigation to Lexus OEM monitors. The device offers simple Plug&Play connection and does not require any additional equipment for installation (like a video interface or some sort of adapter). The navigation box works on Android 6.0.1, which allows users to expand the functionality with different applications from Google Play. This box is equipped with inputs for connecting a rear view or front view camera.
This navigation box is equipped with a built-in smartphone mirroring function, which allows you to connect and use your Android or iOS smartphone on the car monitor.
Why do you need a navigation box?
It's quite simple, really: it will help you to quickly get your bearings in an unfamiliar place and find an optimal route to your destination. All information and hints about the route will be on your car monitor. There's no need to connect a smartphone and spoil the look of your car with cables or dock station.
Features
- Simple Plug&Play navigation connection to the OEM monitor
- Built-in smartphone mirroring function (connect Android and iOS smartphones)
- Play media content
- Connect to the Internet via Wi-Fi
- AV input for connecting additional video sources
- Input for front/rear view camera connection
- Sleep mode (last used application is remembered after parking)
- Control using OEM joystick or touchpad
- USB input
- LVDS output
Compatibility
Brand | Series | Model years | Monitor size | Additional compatibility condition | |
---|---|---|---|---|---|
From | To | ||||
Lexus | CT | 2013 | – | 8" / 12.3" | Head unit with OEM joystick |
ES | |||||
GS | |||||
IS | |||||
LX | |||||
RX | |||||
LC | 2014 | 2017 | 7" / 12.3" | Head unit with OEM touchpad | |
LS | |||||
NX | |||||
RC |
Technical Specifications
System | OS | Android 6.0.1 |
RAM | 2 GB | |
eMMC | 16 GB | |
Outputs | LVDS | 1 |
Stereo audio output | 1 | |
Inputs | AV | 1 |
USB | 1 | |
General | Resolution | 800×480; 1280×480 |
Cold start | 40 s | |
Hot start | 6 s |
The photo is provided for reference only. Appearance of the control panel and monitor may slightly differ depending on the car model.
Manuals
Package Content
- Navigation box
- Connection cables
- GPS antenna
- External speaker
Note! Navigation software, touch screen panels, controllers, are not included in the package.
Note! Navigation box installation should be performed by well-trained specialist. Otherwise, we are not liable for equipment damage or incorrect operation.
Specifications
Navigation Box is compatible with |
|
Operation System |
|
Wi-Fi Connection |
|
Bluetooth Connection |
|
AV inputs |
|
USB Ports |
|
RAM size |
|
ROM size |
|
