Navigation System for Porsche with CDR+ / PCM3.1 System
Overview
Description
Specifications
Delivery
Payment
Warranty
Discontinued
Contact
sales team
sales team
Overview
1.5 kg Warranty: 12 months
Navigation system with inputs for connecting rear view camera and other aftermarket video sources to Porsche OEM monitors with CDR+ / PCM3.1 system.
Description
Navigation system is equipped with inputs for connecting rear view cameras and other aftermarket video sources to Porsche OEM monitors with CDR+ / PCM3.1 system. Navigation system works on Windows CE 6.0 platform.
This adapter is equipped with the active parking guidelines function (PAS).
Navigation System for Porsche
Features
- Aftermarket navigation on your OEM monitor
- Connect rear view camera
- Play media content
- USB inputs
- Navigation output resolution
- 800×480
Navigation System for Porsche
Technical Specifications
| System | CPU | Telechips TCC8801 (2.12GHz ARM Cortex A8) |
| OS | Windows CE 6.0 | |
| Supported formats | Audio | MP3, WMA, MP2, OGG, AAC, FLAC, APE |
| Video | AVI, ASF, MPG, MP4, RMFF, FLV, M2TS, TS/TP, MKV, WMV | |
| Navigation | Supported systems | GPS |
| Outputs | RGB | 800 × 480 |
| LVDS | 1 | |
| Inputs | AV | 1 |
| Rear view camera connection | 1 | |
| Data | USB | USB 2.0×1 |
| Slot for memory card | SDHC (~ 32 GB) | |
| General | Power | 10 - 16 V |
| Screen type | LCD |
Navigation System for Porsche
Compatibility
| Brand | Model | Model years | System | |
|---|---|---|---|---|
| From | To | |||
| Porsche | Cayenne | 2011 | – | CDR+ PCM3.1 |
| Panamera | 2010 | |||
Navigation System for Porsche
Manuals
- Download user manual for the navigation system
- Download installation manual for the navigation system
Navigation System for Porsche
Package Content
- Navigation system
- Sub-board
- SD sub-board
- Connection cables
- Power cable×2
- LVDS cable
- FFC cable×2
- FPC cable
- AV/BT cable
- Rear view camera cable
- Mode switch cable
- USB cable
- OEM button cable
- Extension cables×2
- Multi cables
- SD extension cable
- GPS antenna
- DMB antenna
- External speaker
Note! Installation of the navigation system should be performed by a well-trained specialist. Otherwise, we are not liable for equipment damage or incorrect operation.
Read more
Description
Navigation system is equipped with inputs for connecting rear view cameras and other aftermarket video sources to Porsche OEM monitors with CDR+ / PCM3.1 system. Navigation system works on Windows CE 6.0 platform.
This adapter is equipped with the active parking guidelines function (PAS).
Navigation System for Porsche
Features
- Aftermarket navigation on your OEM monitor
- Connect rear view camera
- Play media content
- USB inputs
- Navigation output resolution
- 800×480
Navigation System for Porsche
Technical Specifications
| System | CPU | Telechips TCC8801 (2.12GHz ARM Cortex A8) |
| OS | Windows CE 6.0 | |
| Supported formats | Audio | MP3, WMA, MP2, OGG, AAC, FLAC, APE |
| Video | AVI, ASF, MPG, MP4, RMFF, FLV, M2TS, TS/TP, MKV, WMV | |
| Navigation | Supported systems | GPS |
| Outputs | RGB |
800 × 480 |
| LVDS | 1 | |
| Inputs |
AV | 1 |
| Rear view camera connection | 1 | |
| Data | USB | USB 2.0×1 |
| Slot for memory card | SDHC (~ 32 GB) | |
| General | Power | 10 - 16 V |
| Screen type | LCD |
Navigation System for Porsche
Compatibility
| Brand | Model | Model years | System | |
|---|---|---|---|---|
| From | To | |||
| Porsche | Cayenne | 2011 | – | CDR+ PCM3.1 |
| Panamera | 2010 | |||
Navigation System for Porsche
Manuals
- Download user manual for the navigation system
- Download installation manual for the navigation system
Navigation System for Porsche
Package Content
- Navigation system
- Sub-board
- SD sub-board
- Connection cables
- Power cable×2
- LVDS cable
- FFC cable×2
- FPC cable
- AV/BT cable
- Rear view camera cable
- Mode switch cable
- USB cable
- OEM button cable
- Extension cables×2
- Multi cables
- SD extension cable
- GPS antenna
- DMB antenna
- External speaker
Note! Installation of the navigation system should be performed by a well-trained specialist. Otherwise, we are not liable for equipment damage or incorrect operation.
Product specifications, appearance and package content may differ from those presented on the website and can be changed without notice. Please, contact sales manager before purchase.
Note! Car Solutions is not liable for device incorrect operation in case of unauthorised OS upgrade. If you have problems with navigation box original OS operation, describe your situation on our forum, and our technical specialists will provide the solution.
