Navigation System for Toyota Touch&Go Based on CS9900 (Car Solutions Edition)
Overview
Description
Navigation system based on CS9900 box is aimed at expanding navigation functions of Toyota cars with Touch & Go and Touch & Go Plus monitors! You just connect this navigation box to the monitor and receive fully functional navigation with the required interface language and maps, and touch screen control. The device provides Plug&Play connection without damaging OEM wires.
The navigation box works under Android platform allowing you to expand the device functionality by various programs and application from Google Play.
*Note! MAP/Nav button on the monitor is the basic requirement for compatibility.
*Note! Before purchase, please, inform the manager about the manufacturer of your monitor. We will prepare the package for installation directly for your head unit.
Compare CS9100/CS9200/CS9900/KD-900/Andromeda navigation boxes.
Navigation System for Toyota Touch&Go
Advantages
- Navigation image activation by OEM button (double press Mute button)
- Voice prompts playback via car speakers
- Drag and scrolling functions on the touch screen
Navigation System for Toyota Touch&Go
Additional Features
Navigation Box Functionality Expansion
- Internet connection
Connection to the Internet via 3G modem (included in the package). Wi-Fi connection with the help of USB adapter (included in the package). - USB devices connection. You can connect 4 USB devices with more than 500 mA current consumption without USB booster
Expanded Multimedia Features
You can install a lot of programs and applications (be it games or widgets) which would significantly expand multimedia features of your navigation box and car monitor.
OEM Antenna Connection
Specially developed adapter allows you to connect navigation box to OEM GPS antenna which provides high quality signal and easier installation.
Navigation System for Toyota Touch&Go
Compatibility
Toyota Touch & Go / Touch & Go + Monitors
 |
 |
 |
 |
| Toyota model | Model Years | Monitor | |
|---|---|---|---|
| From | To | ||
| Auris | 2010 | 2014 | Touch & Go Touch & Go Plus |
| Auris Hybrid | 2010 | 2014 | |
| Avensis | 2011 | 2014 | |
| Camry | 2011 | 2014 | |
| Camry Hybrid | 2012 | 2014 | |
| Corolla | 2011 | 2013 | |
| GT86 | 2012 | 2014 | |
| Highlander | 2012 | 2014 | |
| Highlander Hybrid | 2012 | 2014 | |
| Hilux | 2011 | 2014 | |
| Matrix | 2011 | 2014 | |
| Prius | 2011 | 2014 | |
| Prius C | 2012 | 2014 | |
| Prius MPV+ | 2012 | 2014 | |
| Prius Plug-in Hybrid | 2012 | 2014 | |
| RAV4 | 2010 | 2014 | |
| Tacoma | 2012 | 2014 | |
| Venza | 2013 | 2014 | |
| Verso | 2009 | 2014 | |
| Verso S | 2010 | 2014 | |
| Yaris | 2011 | 2014 | |
| Yaris Hybrid | 2012 | 2014 | |
How to Identify the Manufacturer of Touch&Go (Plus) Monitor
*Note! Before purchase, please, inform the manager about the manufacturer of your monitor. We will prepare the package for installation directly for your head unit.
Navigation System for Toyota Touch&Go
Technical Specifications
| System | Processor | A8 / Cortex 1 GHz |
| OS | Android 2.3.7 | |
| Language | Multilanguage support | |
| Memory | ROM | 4 GB |
| RAM | DDR3 1 GB | |
| Memory cards | MMC, miniSD, SD, SDHC up to 32 GB (depends on the manufacturer) |
|
| Video outputs | RGB supported resolutions: |
480×234, 640×480, 800×480 |
| RCA | CVBS | |
| Audio outputs | RCA | linear stereo |
| TS 3.5 mm | 0.25 W dynamics socket (mono) | |
| Audio input | TS 3.5 mm | for microphone |
| Data | USB (4) | A type (for external devices 5 V / 1 A) |
| Control | Radio remote controller | with touch panel |
| Touch screen panel | Direct connection | |
| Car OEM control buttons | Via touch adapter | |
| GPS | Chipset | MTK MT3329T |
| Channels | 66 | |
| Frequency | L1 1575,42 MHz | |
| Sensitivity | -165 dB | |
| Reacquisition | 1 s | |
| Protocol | GPGGA (1 time/1 s), GPGSA (1 time/5 s), GPGSV (1 time /5 s), GPRMC (1 time /1 s), GPVTG (1 time/1 s), (additionally GLL or MTK NMEA Command) |
|
| Hot/warm/cold start | 1 s / 28 s /30 s | |
| Antenna | SMA, active | |
| Power | 10-30 V DC | – |
Navigation System for Toyota Touch&Go
Package Content
- CS9900 navigation box main board
- Universal touch screen adapter
- AVP manager module
- 3G modem
- USB Wi-Fi adapter
- Remote control
- GPS antenna
- 8 GB memory card
- Connection cables set
Note! Navigation box installation shall be performed by well-trained specialist. Otherwise, we are not liable for equipment damage or incorrect operation.
