Q-ROI Navigation System on Android with Monitor for BMW 5 Series
id: 862693
Q-ROI Navigation System on Android with Monitor for BMW 5 Series
Overview
Description
Specifications
Delivery
Payment
Warranty
Discontinued
Overview
1.5 kg Warranty: 12 months
Q-ROI navigation system with inputs for connecting rear view camera and other aftermarket video sources to OEM monitors of BMW 5 series cars. Read more
Description
Q-ROI navigation system with inputs for connecting rear view cameras and other aftermarket video sources to BMW 5 series OEM monitors. Navigation system works on Android 4.2.2 platform allowing you to expand the device functionality by various programs and applications from Google Play.
This adapter is equipped with the active parking guidelines function (PAS).
Features
- Aftermarket navigation on your OEM monitor
- Connect rear view camera
- Play media content
- USB inputs
- Navigation output resolution
- 800×480
Technical Specifications
| System: | CPU | Telechips TCC8930 (1GHz Cortex A9 DualCore) |
| OS | Android 4.2.2 Jelly Bean | |
| RAM | DDR3 1 GB | |
| ROM | 8 GB eMMC | |
| Language | Multilingual | |
| GPS | Supported systems | GPS |
| Chipset | SiRF | |
| Outputs | RGB |
800 × 480 |
| 480 × 234 | ||
| LVDS (6-pin) | 1 | |
| Inputs |
AV | 3 |
| Rear view camera connection | 1 | |
| Data | USB | USB 2.0 × 4 |
| OTG USB ×1 | ||
| Slot for memory card | SDHC (up to 64 GB) | |
| General | Power | 12 V |
| Supported type of touch screen | Resistive |
Compatibility
| Series | Body | Display size | Model Years | System | |
|---|---|---|---|---|---|
| From | To | ||||
| 5 Series | F10 | 6,5″ 8,8″ 10,2″ |
2012 | 2015 | iDrive NBT CIC |
| F11 | |||||
Note! For installation of the navigation system it is necessary to replace your monitor with the one incuded in the package content.
Manuals
- Download user manual for Q-ROI navigation system
- Download installation manual for Q-ROI navigation system
Package Content
- 10.2" monitor
- Sub-board
- Connection cables
- Power cable
- AV cable
- Rear view camera cable
- Mode switch cable
- USB cable
- Microphone cable
- Multi cables
- SD extension cable
- GPS antenna
- Wi-Fi dongle
- 3G dongle
Note! Installation of the navigation system should be performed by a well-trained specialist. Otherwise, we are not liable for equipment damage or incorrect operation.
Product specifications, appearance and package content may differ from those presented on the website and can be changed without notice. Please, contact sales manager before purchase.
Note! Car Solutions is not liable for device incorrect operation in case of unauthorised OS upgrade. If you have problems with navigation box original OS operation, describe your situation on our forum, and our technical specialists will provide the solution.
All rights reserved. This material from car-solutions.com web site may not be published, rewritten or redistributed in whole or part without authorship indicated and backlinks provided.
