Universal Car Camera CS-C0007
when in stock
Universal car camera CS-C0007 in waterproof case is a very useful device, a "must-have" for each car owner, which considerably simplifies the parking process.
By default, it is a rear view camera with static parking guidelines, but it can also be used as a front or a side view camera. To use it as the front/side view camera, cut one of the following wires:
- green if you want to disable parking guidelines
- white if you want to use it as the frond/side view camera
Universal car camera CS-C0007 in waterproof case is a very useful device, a "must-have" for each car owner, which considerably simplifies the parking process.
By default, it is a rear view camera with static parking guidelines, but it can also be used as a front or a side view camera. To use it as the front/side view camera, cut one of the following wires:
- green if you want to disable parking guidelines
- white if you want to use it as the frond/side view camera
At the moment, the two most popular connectors on the market are RCA (tulip) and 4PIN.
This camera is equipped with 4PIN connector, which is much thinner compared to RCA, makes the installation even more convenient, since the cable is easier to push through the nodes of the car.
Features
- Color image
- Waterproof case
- Easy installation
- High definition image
Technical specifications
| Viewing angle | 170° |
| Video system | PAL/NTSC |
| Image sensor | 1/4 CMOS |
| Dimensions (L/W/H) | 26 × 28 × 24 mm |
| Effective pixels | 733 × 493 |
| Resolution | 480 TVL |
| Operating voltage | DC 12 V |
| Weight | 252 g |
| Operating temperature | -20°~70°C |
| Connectors | 4pin × 1 |
| Color | Black |
| Case | Waterproof (IP67) |
Package contents
- Universal car camera
- Set of connection cables
