Video Interface for Toyota Touch 2 with Parking Guidelines

ID: 862651
ID: 862651 1.5 kg
Car video interface for Toyota Touch 2 head units. Supports the parking guidelines function (PAS). Connected DVD and TV media devices can be controlled with OEM touch screen.
Discontinued
Contact
sales team
Discontinued
Contact
sales team
Add to wishlist
Suggest your price
Impossible to estimate the shipping cost
Overview
Specifications
Delivery
Payment
Warranty
Overview

Car video interface is used to connect external video sources, such as navigation box, as well as a rear view camera or a front view camera with adaptive parking guidelines, to Toyota Touch 2 OEM car monitors. This video adapter is designed for Toyota cars with Toyota Touch 2 head units.

This interface allows controlling connected DVD, HD players or TV receivers using the OEM touch screen.

The most frequently asked questions about video interfaces.

Car Video Interface for Toyota
Technical Specifications

  • Inputs:
    • CVBS input for rear view camera connection
    • CVBS input for front view camera connection
    • A/V input x 2
    • LVDS input
    • RGB input for navigation system connection
  • Output:
    • Output for LCD connection
  • Power
    • Input power: 8 V DC ~ 24 V DC
    • Max. consumed power: 12 W
  • Mode switching:
    • it is possible to skip AV source by DIP S/W

Car Video Interface for Toyota
Video

Car Video Interface for Toyota
Compatibility

Toyota Model

Model years Compatible monitor
(head unit)
Additional conditions
From To
Auris 2014 Touch 2 Only Panasonic monitors with MAP / NAVI button
Avensis 2014
Camry 2014
Corolla 2013
Corolla Sedan 2013
Highlander 2013
Hilux 2013
Land Cruiser 150 2013
Prius 2014
RAV4 2014
Verso 2014


Toyota Campry
Toyota Camry
Toyota RAV4
Toyota RAV4
Toyota Prius
Toyota Prius

Car Video Interface for Toyota
Manuals

Car Video Interface for Toyota
Package Content

  • Car video interface main module
  • OSD keypad
  • Cable set:
    • LVDS cable
    • RGB cable
    • A/V cable
    • Power cable
    • Navigation box power cable
    • Cable with mode switch button
    • Touch IN/OUT cable
If you have questions concerning this product or want to share your experience of its installation or application, visit our forum.
*Product package content and appearance may differ from those presented on the website and depend on video interface version. Please, ask sales manager before purchase.
Note! The video interface must be installed only by the high skilled specialists. In case the device is installed incorrectly the car electronics can be damaged or go out of order.
We are not liable for damage or incorrect operation of the equipment in the case of improper installation.
All rights reserved. This material from car-solutions.com web site may not be published, rewritten or redistributed in whole or part without authorship indicated and backlinks provided.
Specifications
Video Interface is compatible with the following models of Cars
  • Toyota
Video Interface is compatible with Head Units
  • Touch 2
Touch screen control of the connected devices
  • Yes
Adaptive parking guidelines
  • Yes
Modes switch by OEM buttons
  • Yes
CAN bus support
  • Yes
DVD/HD/TV connection input
  • Yes
Navigation input
  • Yes
Rear view camera input
  • Yes
Built-in navigation
  • No
