Q-ROI Navigation System on Android for Mercedes-Benz W204 of 2012-2014 MY
sales team
Q-ROI navigation system with inputs for connecting rear view cameras and other aftermarket video sources to Mercedes-Benz W204 OEM monitors. navigation system works on Android 4.2.2 platform allowing you to expand the device functionality by various programs and applications from Google Play.
This adapter is equipped with the parking guidelines function (PAS).
Q-ROI Navigation System for Mercedes
Features
- Aftermarket navigation on your OEM monitor
- Connect rear view camera
- Play media content
- USB inputs
- Navigation output resolution
- 800×480
- 480×234
Q-ROI Navigation System for Mercedes
Technical Specifications
| System: | CPU | Telechips TCC8930 (1GHz Cortex A9 DualCore) |
| OS | Android 4.2.2 Jelly Bean | |
| RAM | DDR3 1 GB | |
| ROM | 8 GB eMMC | |
| Language | Multilingual | |
| GPS | Supported systems | GPS |
| Chipset | SiRF | |
| Outputs | RGB | 800 × 480 |
| 480 × 234 | ||
| LVDS | 1 | |
| Inputs | AV | 3 |
| Rear view camera connection | 1 | |
| Data | USB | USB 2.0 × 4 |
| OTG USB ×1 | ||
| Slot for memory card | SDHC (up to 64 GB) | |
| General | Power | 12 V |
| Supported type of touch screen | Resistive |
Q-ROI Navigation System for Mercedes
Compatibility
| Class | Body | Model year | Compatibility condition | |
|---|---|---|---|---|
| From | To | |||
| A | W176 | 2012 | 2014 | HU with round connector |
| B | W246 | |||
| C | W204 | |||
| CLA | C117 | |||
| E | W212 | |||
| GLK | X204 | |||
| ML | W166 | |||
Q-ROI Navigation System for Mercedes
Manuals
- Download user manual for Q-ROI navigation system
- Download installation manual for Q-ROI navigation system
Q-ROI Navigation System for Mercedes
Package Content
- Q-ROI navigation system
- Sub-board
- Connection cables
- Power cable
- LVDS cable
- TOUCH cable
- AV/BT cable
- LCD cable
- Rear view camera cable
- Mode switch cable
- USB cable
- Microphone cable
- Multi cables
- GPS antenna
- External speaker
- Wi-Fi dongle
- 3G dongle
Note! Installation of the navigation system should be performed by a well-trained specialist. Otherwise, we are not liable for equipment damage or incorrect operation.
